HS2 - Enabling Works South

HS2 is the new rail infrastructure that will connect the North with the South. From London to Birmingham on to Manchester and then Leeds. Connecting over 345 miles of High-Speed trains, carrying over 300,000 passengers per day.

CAD ON Track are providing their services to HS2 for the use of BIM, CAD specifications and procedures and underground utilities knowledge.

Click on the Image above to go to the HS2 EWS photogrammetry web viewer page.

London Bridge Station Redevelopment

London Bridge Station Redevelopment was part of the Thameslink Programme overhaling to improve passenger capacity within the station. The 5 year project maintained a fully running station, whilst it transformed the original 1830s station into a larger, modern station fit for the 21st century.

CAD ON Track provided their services to Costain with their capabilities to model from laser scan data and manage the underground utilities data.

Blackfriars Station

London Blackfriars Station was part of Network Rails Thameslink K01 redevelopment project. This landmark London Station spans the River Thames and has two entrances either side of the river.

At the time of this project, Gareth worked for Network Rail and used his skill to model from laser scan, textured up the 3D CAD model to then provide a 4D visual walkthrough for options on Real Time Information display boards.
